MTS-SMDF fiber dual color infrared thermometer

Model: MTS-SMDF
Category: Infrared temperature sensor
Range: 200 ℃ to 3000 ℃
Sensors: Silicon, InGaAs
Wavelength: 0.9-1.7 μ m, 0.7-1.08 μ m, 1.7 μ m, 1.08 μ m
Signal output mv, 0-5vdc, 0-10vdc, 4-20mA, PNP, relay, RS485
Measurement accuracy: 0.5%,
Repeatability accuracy: 2 ℃,
Resolution: 0.1 ℃
Response time: 5ms
Application: Heat treatment, metal forging, casting, induction heating, glass, semiconductor, induction heating, heat treatment, single crystal, polycrystalline silicon, vacuum furnace, high-temperature furnace




we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Online Sales

MTS-MRSF fiber monochromatic infrared pyrometer
Model: MTS-MRSF
Category: Infrared temperature sensor
Measurement range: 600-1600, 600-2000, 700-2500, 700-3000.
Sensors: Silicon, InGaAs
Wavelength: (0.85-1.1) μ m, (1.45-1.7) μ m
Signal output mv, 0-5vdc, 0-10vdc, 4-20mA, PNP, relay, RS485
Measurement accuracy: 0.5%,
Repeatability accuracy: 2 ℃,
Resolution: 0.1 ℃
Response time: 5ms
Application: Heat treatment, metal forging, casting, induction heating, glass, semiconductor, induction heating, heat treatment,
Single crystal, polycrystalline silicon, vacuum furnace, high-temperature furnace infrared thermometer, non-contact infrared high-temperature instrument, fiber optic infrared high-temperature instrument, monochromatic infrared high-temperature machine

MTS-SMDF fiber dual color infrared thermometer-MANYYEAR TECHNOLOGY

Technical Parameters



model

MTS-SMDF

FGR-4014

MTS-SMDF

FGR-4522

MTS-SMDF

FSR-6016

MTS-SMDF

FSR-7025

MTS-SMDF

FSR-8030

Measuring range

(℃)



400~1400



450~2200



600~1600



700~2500



800~3000

detectorInGaAs/InGaAsSi/Si (stacked silicon)


Working wavelength

Wavelength 1: (0.9-1.7) μ M,

Wavelength 2:1.7 μ M

Wavelength 1: (0.7~1.08) μ M,

Wavelength 2:1.08 μ M

Main applicationsContinuous casting, hot rolling, induction heating, polycrystalline silicon and monocrystalline silicon, temperature measurement in high-temperature environments
Distance coefficient50:1100:150:1100:1200:1
Measure distanceAdjustable focal length from 0.15m to infinity
measurement accuracy± 0.5% T (T is the reading temperature), higher precision customizable
Temperature resolution0.1 ℃
Repetitive accuracy± 2 ℃
Monochromatic coefficient0.100~1.100, adjustable step distance of 0.001
Bicolor coefficient0.850~1.150, adjustable step distance of 0.001
response time5ms~99.99s adjustable, customizable for faster speeds


signal processing

Peak, valley, average, and alarm for high or low ambient temperature,

Single color and dual color switchable, with power-off protection and other functions









output

The first group of multiple analog outputs (4mA~20mA, 0mA~20mA, 0V~5V, 0V~10V can be switched),

Output resolution of 16 bits, accurate to 0.1 ℃, maximum load of 600 Ω for current loop output, allowable current of 10mA for voltage output

The second group of analog signals outputs 4mA to 20mA with a resolution of 1 ℃ and a maximum load of 600 Ω for the current loop output, with a 12bit output
Alarm output: Upper and lower limit alarms, using optocoupler relays with unlimited service life,

Conduction resistance ≤ 2 Ω, maximum allowable voltage AC42V or DC60V, maximum allowable current 120mA, response time 2ms

PNP level output (output current 100mA, with overload protection)
RS485 output, capable of parameter modification, data recording, and querying functions
Display methodAdopting self luminous industrial grade OLED display screen


Power supply

DC (20-30) V, with overvoltage, overcurrent, and short circuit protection, power consumption: 5W( 24V@200mA )

Built in EMI filter, can resist interference from 2500VDC pulse group.

Environmental temperature

Degree compensation



Equipped with a built-in 40 ℃ constant temperature heater and full temperature compensation, the temperature measurement accuracy is almost unaffected by the ambient temperature.

sighting systemBuilt in visible red laser aiming


Usage environment

Temperature measuring instrument without water cooling: -20 ℃ to+60 ℃,

Thermometer with water cooling: -20 ℃~+200 ℃ (cooling water pressure is 0.2MPa, flow rate is 2L/min) Lens and optical fiber: -20 ℃~+250 ℃ (blowing pressure is 0.1MPa, flow rate is 6L/min)

Protection levelIP65



Display Interface

MTS-SMDF fiber dual color infrared thermometer-MANYYEAR TECHNOLOGY

Infrared light path diagram

MTS-SMDF fiber dual color infrared thermometer-MANYYEAR TECHNOLOGY

  • Aiming Requirements

MTS-SMDF fiber dual color infrared thermometer-MANYYEAR TECHNOLOGY

Angle of Installation

MTS-SMDF fiber dual color infrared thermometer-MANYYEAR TECHNOLOGY

Air-cooled pipe

MTS-SMDF fiber dual color infrared thermometer-MANYYEAR TECHNOLOGY
