MLC928DAH platform scale load cell

body scale load cell,vending machine load cell,force load cell,platform scale load cell

Model: MLC928DAH
Catalog: Micro load cell
Rated load: 150kg,200kg
Dimension:45*45*3.5mm
Material: alloy steel
Safe overload:120%; Ultimate overload: 150%
Characteristic:body scale load cell, vending machine load cell,force load cell,platform scale load cell,electronic warehouse load cell


we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Online Sales



Product Picture Reference

MLC928DAH platform scale load cell-MANYYEAR TECHNOLOGY

Technology Specification

Below spec is only for customer design reference,we can provide ODM product.
MLC928DAH platform scale load cell

Model: MLC928DAH

Catalog: Micro load cell

Rated load: 150,200kg

Dimension:45*45*3.5/4.5mm

Material: alloy steel

Safe overload:120%; Ultimate overload:150%

Characteristic:body scale load cell, vending machine load cell,force load cell,platform scale load cell,electronic warehouse load cell

 Specification
Comprehensive error:0.1%FSOutput resistance:1000±10Ω
Rated output (full bridge):1.0/1.5±0.15mV/VInsulation resistance:≥2000MΩ(100VDC)
Non-linearity:0.05%FSExcitation voltage:5~10VDC
Hysteresis:0.05%FSCompensated temp:-10~+50ºC
Repeatability:0.05%FSUse temperature:-20~+55ºC
Creep:0.1%FS/3MinTemp effect on zero:0.1%FS/10ºC
Zero balance:1±0.1%FSTemp effect on span:0.05%FS/10ºC
Input resistance:1000±10ΩDefend grade:IP66



Product Dimension

MLC928DAH platform scale load cell-MANYYEAR TECHNOLOGY

Force Structure & Assembly Reference

MLC928DAH platform scale load cell-MANYYEAR TECHNOLOGY

Product Application

MLC928DAH platform scale load cell-MANYYEAR TECHNOLOGYMLC928DAH platform scale load cell-MANYYEAR TECHNOLOGYMLC928DAH platform scale load cell-MANYYEAR TECHNOLOGY
