MLC595 mechanical torque sensor

2021/11/17 Static Torque Sensor Torque Sensor 2416 0

Static torque sensor, the pump torque sensor, the gearbox torque load cell, torque wrench sensor

Model MLC595
Category Torque sensor
Range 0-100Nm, 1K, 2k, 5K 10KNm
Material alloy steel
Signal output mv/v, 0-10vdc, 4-20mA, RS485
Application: Static torque sensor, mechanical torque sensor, Engineering torque sensor, Torque testing machine torque sensor

we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Online Sales

Product Introduction Technical Documents

Product Picture Reference

Technology Specification

Below spec is only for customer design reference. we can provide ODM product.

MLC595 car power torque sensor

Range	0-50,100,200,500,1000Nm	Input resistance	700±5Ω
Rated Output	1.5±10% mV / V	insulation	≥5000MΩ/ 100VDC
Zero Output	±2% F.S.	Work voltage	10-15VDC
Nonlinearity	±0.1，0.3% F.S.	Compensated Temp.	-10 ~ 60℃
Hysteresis	≤±0.05% F.S.	operating Temp.	-20 ~ 65℃
Repeatability	≤±0.05% F.S	Safty overload	150% F.S.
Creep	≤±0.03% F.S/30min	Ultimate overload	200% F.S.
Ratedoutput drift by temp.	0.03% F.S. / 10℃	Wire	Ø5.2×3m
Zero drift by temp.	0.03% F.S. / 10℃	Electric connect	RED/E+，BLK/E-，GRN/S+，WHT/S-
Input resistance	750±10Ω	Material	stainless steel or alloy steel

Product Dimension

Force Structure & Assembly Reference

Static torque sensor installation
