MLC5115 Double range Static torque sensor MLC5115 Double range Static torque sensor
MLC5115 Double range Static torque sensor
MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY
MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

MLC5115 Double range Static torque sensor

Double range Static torque sensor,motors torque sensor, Mechanical torque sensor, Torque testing machine torque sensor

Model MLC5115
Category Torque sensor
Range 0-20, 100, 1000, 5000Nm
Material alloy steel
Signal output mv/v, 0-10vdc, 4-20mA, RS485
Application: Double range Static torque sensor,motors torque sensor, Mechanical torque sensor, Torque testing machine torque sensor


we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

  Product selection reference

Online Sales



Product Picture Reference

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

MLC5115 Double range Static torque sensor

Technology Specification

Below spec is only for customer design reference. we can provide ODM product.
MLC5115 Double range Static torque sensor

Range0-20,100,1000,5000NmResonant Frequency100μS
Rated Output1.5±10% mV / Vinsulation≥5000MΩ/ 100VDC
Zero Output±1% F.S.Work voltage10VDC(9-15VDC)
Nonlinearity±0.1,0.3% F.S.Compensated Temp.-10 ~ 60℃
Hysteresis≤±0.05% F.S.operating Temp.-20 ~ 65℃
Repeatability≤±0.05% F.SSafty overload150% F.S.
Creep≤±0.03% F.S/30minUltimate overload200% F.S.
Ratedoutput drift by temp.0.03% F.S. / 10℃WireØ5.2×3m
Zero drift by temp.0.03% F.S. / 10℃Electric connectRED/E+,BLK/E-,GRN/S+,WHT/S-
Input resistance350,750±10ΩMaterialaluminium,stainless steel or alloy steel
Input resistance350,700±5ΩOthers Customizabler

Product Dimension

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

MLC5115 Double range Static torque sensor

Force Structure & Assembly Reference

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

Static torque sensor installation

Product Application

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

APF-torque testing machine

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

APF-Viscometer

MLC5115 Double range Static torque sensor-MANYYEAR TECHNOLOGY

APF-Mechanical Torque
