MLC204EA miniature button force load cell

MLC204EA Robot Intelligent Switch Micro Force Measuring Button Micro Force Measuring Sensor 2000kg

Model: MLC204EA
Category: Button type weighing sensor
Range: 10kg, 20kg, 50kg, 75kg, 100kg, 150kg, 200kg
Size: D35.7 * 23.8mm
Wire size: Φ 4x3m
Material: Alloy steel, stainless steel
Safety overload 120% F.S. Extreme overload: 150% F.S
Application: Robot intelligent switch micro force measuring machine


we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference



Product Picture Reference

MLC204EA miniature button force load cell-MANYYEAR TECHNOLOGY

Technology Specification

Below spec is only for customer design reference. we can provide ODM product.

MLC204WA miniature button force load cell

Model: MLC204EA
Category: Button type weighing sensor
Range: 10kg, 20kg, 50kg, 75kg, 100kg, 150kg, 200kg
Size: D35.7 * 23.8mm
Wire size: Φ 4x3m
Material: Alloy steel, stainless steel
Safety overload 120% F.S. Extreme overload: 150% F.S
Application: Robot intelligent switch micro force measuring machine

Other Dimension (mm)
Specification
Comprehensive error:0.2%FSOutput resistance:350±5Ω
Rated output:1±0.1mV/VInsulation resistance:≥5000MΩ(100VDC)
Non-linearity:0.2%FSExcitation voltage:9~12VDC
Hysteresis:0.2%FSCompensated temp:-10~+40ºC
Repeatability:0.1%FSUse temperature:-20~+55ºC
Creep:0.03%FS/10MinTemp effect on zero:0.05%FS/10ºC
Zero balance:±5%FSTemp effect on span:0.05%FS/10ºC
Input resistance:350±5ΩDefend grade:IP66

Product Dimension

MLC204EA miniature button force load cell-MANYYEAR TECHNOLOGY

Force Structure & Assembly Reference

MLC204EA miniature button force load cell-MANYYEAR TECHNOLOGY

Product Application

MLC204EA miniature button force load cell-MANYYEAR TECHNOLOGYMLC204EA miniature button force load cell-MANYYEAR TECHNOLOGYMLC204EA miniature button force load cell-MANYYEAR TECHNOLOGY
