MLC638 packing scale weighing sensor

2021/11/12 Weighing Load Cell MLC600 Parallel Beam Load Cell 2276 0

platform scale weighing sensor,packing scale weighing sensor,batching scale weighing sensor,checkweigher weight sensor.

Model: MLC638
Category: Single point load cell
Range: 30kg,50kg,60kg,100kg,150kg,200kg,300kg,350kg,500kg
Dimension: 150*40*35mm
Material: alloy aluminum
Characteristic: platform scale weighing sensor,packing scale weighing sensor,batching scale weighing sensor,checkweigher weight sensor.

Product selection reference

Sales Online

Product Introduction Technical Documents

Product Picture Reference

MLC638 packing scale weighing sensor

Technology Specification

Below spec is only for customer design reference,we can provide ODM product.

MLC638 packing scale weighing sensor

Model: MLC638 Category: Single point load cell Range: 30kg,50kg,60kg,100kg,150kg,200kg,300kg,350kg,500kg Dimension: 1504035mm Material: alloy aluminum Characteristic: platform scale weighing sensor,packing scale weighing sensor,batching scale weighing sensor,checkweigher weight sensor

Specification
Comprehensive error:	0.017%FS	Output resistance:	350±3Ω
Rated output:	1±0.01mV/V	Insulation resistance:	≥5000MΩ(100VDC)
Non-linearity:	0.017%FS	Excitation voltage:	9~12VDC
Hysteresis:	0.017%FS	Compensated temp:	-10~+40ºC
Repeatability:	0.01%FS	Use temperature:	-20~+60ºC
Creep:	0.017%FS/10Min	Temp effect on zero:	0.017%FS/10ºC
Zero balance:	±1%FS	Temp effect on span:	0.014%FS/10ºC
Input resistance:	405±10Ω	Defend grade:	IP65

Product Dimension

Force Structure & Assembly Reference

Product Application

weighing solution-cinema seats management system
Bus seat weighing solution is applicable to bus seat weighing and counting control.
wireless truck weighing system
Bus seat weighing solution is applicable to bus seat weighing and counting control.
seat weighing system solution
Bus seat weighing solution is applicable to bus seat weighing and counting control.
platform scale weighing solution
weighing solution is applicable to price scale, kitchen scale, pet scale, truck scale, belt scale, packaging scale, batching scale, inspection scale, tank scale etc
