MLC623 checkweigher load cell

MLC600-20kg Weighing Load Cell 3822 0

Platform scale weighing sensor, pricing scale weighing sensor, electronic scale weighing sensor, checkweigher load cell

Model: MLC623
Category: Single point load cell
Range: 5kg,10kg,20kg,50kg,60kg,75kg,100kg,120kg,150kg,200kg
Dimension: 150*40*30mm
Material: alloy aluminum
Characteristic: platform scale weighing sensor,pricing scale weighing sensor,electronic scale weighing sensor,checkweigher load cell


we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference



Product Picture Reference

MLC623 checkweigher load cell-MANYYEAR TECHNOLOGY

MLC623 checkweigher load cell

Technology Specification

Below spec is only for customer design reference,we can provide ODM product.

MLC623 checkweigher load cell

Model: MLC623

Category: Single point load cell

Range: 5kg,10kg,20kg,50kg,60kg,75kg,100kg,120kg,150kg,200kg

Dimension: 150*40*30mm

Material: alloy aluminum

Characteristic: platform scale weighing sensor,pricing scale weighing sensor,electronic scale weighing sensor,checkweigher load cell

Specification
Comprehensive error:0.017%FSOutput resistance:350±3Ω
Rated output:1±0.01mV/VInsulation resistance:≥5000MΩ(100VDC)
Non-linearity:0.017%FSExcitation voltage:9~12VDC
Hysteresis:0.017%FSCompensated temp:-10~+40ºC
Repeatability:0.01%FSUse temperature:-20~+60ºC
Creep:0.017%FS/10MinTemp effect on zero: 0.017%FS/10ºC
Zero balance:±1%FSTemp effect on span:0.014%FS/10ºC
Input resistance:405±10ΩDefend grade:IP65



Product Dimension

MLC623 checkweigher load cell-MANYYEAR TECHNOLOGY

Force Structure & Assembly Reference

MLC623 checkweigher load cell-MANYYEAR TECHNOLOGY

Product Application
