MLC611N03BA platform scale load cell

MLC600-20kg Weighing Load Cell 3486 0

high temperature load cell, low temperature load cell,kitchen scale load cell, platform scale load cell,vending machine load cell

Model: MLC611N03BA
Category: Micro load cell
Rated load:2,3,5,7.5,10,15,20,25kg
Dimension: 80*68*15mm
Material: alloy aluminum+stainless steel
Characteristic: high temperature load cell, low temperature load cell,kitchen scale load cell, platform scale load cell,vending machine load cell


we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Sales Online



Product Picture Reference



MLC611N03BA platform scale load cell-MANYYEAR TECHNOLOGY

Technology Specification

Below spec is only for customer design reference,we can provide ODM product.
MLC611N03BA platform scale load cell

Model: MLC611N03BA

Category: Micro load cell

Rated load:2,3,5,7.5,10,15,20,25kg

Dimension: 80*68*15mm

Material: alloy aluminum+stainless steel

Characteristic: high temperature load cell, low temperature load cell,kitchen scale load cell, platform scale load cell,vending machine load cell

 Specification
Comprehensive error:0.05%FSOutput resistance:1000±10Ω
Rated output:1±0.15mV/VInsulation resistance:≥2000MΩ(100VDC)
Non-linearity:0.05%FSExcitation voltage:5~10VDC
Hysteresis:0.05%FSCompensated temp:-10~+40ºC
Repeatability:0.05%FSUse temperature:-20~+55ºC
Creep:0.05%FS/3MinTemp effect on zero:0.1%FS/10ºC
Zero balance:±0.1mV/VTemp effect on span:0.05%FS/10ºC
Input resistance:1000±10ΩDefend grade:IP66



Product Dimension

MLC611N03BA platform scale load cell-MANYYEAR TECHNOLOGY

Force Structure & Assembly Reference

MLC611N03BA platform scale load cell-MANYYEAR TECHNOLOGY

Product Application

MLC611N03BA platform scale load cell-MANYYEAR TECHNOLOGYMLC611N03BA platform scale load cell-MANYYEAR TECHNOLOGYMLC611N03BA platform scale load cell-MANYYEAR TECHNOLOGY
