MLC502 ring load cell, 10–500 kg, C2 accuracy, alloy steel/stainless steel, 150% safe overload. Through-hole design for axial/compression/bolt preload force measurement.
Model: MLC502
Catalog: Ring Load Cells
Rated load: 10,20,30,50,100,200,300,400,500kg
Accuracy: C2
Safe overload: 150%; ultimate overload: 200%
Material: alloy steel, stainless steel
Features: ring force sensor, gasket force sensor, axial force sensor, extrusion force sensor, preload force sensor
| Technical Parameters | |||
| Comprehensive error: | 0.2%FS | Output resistance: | 352±5Ω |
| Rated output: | 1.2±0.002mv/v | Insulation resistance: | ≥5000MΩ (100VDC) |
| Nonlinearity: | 0.05%FS | Excitation voltage: | 9~15VDC |
| Lag: | 0.05%FS | Compensation temperature: | -10~+40 ℃ |
| Repeatability: | 0.02%FS | Operating temperature: | -40~+80 ℃ |
| Creep: | 0.02%FS/10MIN | Effect of Temp. on zero point: | 0.03%FS/10 ℃ |
| Zero Balance: | ±1%FS | Effect of Temp. on sensitivity: | 0.02%FS/10 ℃ |
| Input resistance: | 400±5Ω | Defense Rating: | IP68 protection level |
