MLC408 Force Sensor
Range: 5t,10t,15t,20t
Dimension: 125*215mm
Material: Alloy Steel, Stainless Steel
Dimension: 125*215mm
Material: Alloy Steel, Stainless Steel
MLC409 Force Sensor
Product Introduction
Model: MLC409
Category: Column Type Force Sensor
Range: 30,50,60,100,150,200,300,400,500,1000,2500,3500t
Accuracy: 0.1%fs
Operating Temperature: -40~+65ºC
Dimension: 197*160mm; 240*230mm; 305*326mm;415*358mm
Material: Alloy Steel, Stainless Steel
Application: Hydraulic Press Force Sensor, Oil Press Force Sensor, Force Testing Machine Sensor, Large Range Load Cell
Category: Column Type Force Sensor
Range: 30,50,60,100,150,200,300,400,500,1000,2500,3500t
Accuracy: 0.1%fs
Operating Temperature: -40~+65ºC
Dimension: 197*160mm; 240*230mm; 305*326mm;415*358mm
Material: Alloy Steel, Stainless Steel
Application: Hydraulic Press Force Sensor, Oil Press Force Sensor, Force Testing Machine Sensor, Large Range Load Cell
Download related documents
Contact immediately
Technical Specifications
MLC409 Force Sensor by ManYear Technology is a high-quality Column Type Force Sensor. Range 30,50,60,100,150,200,300,400,500,1000,2500,3500t, accuracy 0.1%fs, operating temperature -40~+65ºC. Dimension 197*160mm; 240*230mm; 305*326mm;415*358mm. Material: Alloy Steel, Stainless Steel. Applications: Hydraulic Press Force Sensor, Oil Press Force Sensor, Force Testing Machine Sensor, Large Range Load Cell. Keywords: Force Sensor, Tension Compression Force Sensor. ManYear MLC409 delivers high accuracy, stable performance, and long-term reliability, making it an ideal choice for Column Type Force Sensor measurement in industrial applications. Trusted quality assurance and dedicated technical support are provided for customers worldwide.
