MLC142 Vehicle-Mounted Load Cell, micro bridge-type (500N). Alloy/stainless steel, -20~+55℃, IP65, compact, precise measurement.
MLC142 is a micro bridge-type sensor developed for precise force measurement scenarios, has a measuring range of 500N, widely suitable for vehicle-mounted weighing, elevator weighing, stress deformation detection and various force measurement needs. Made of high-quality alloy steel and stainless steel, it features high stability and anti-interference ability, with an operating temperature range of -20~+55℃ and protection class IP65, easily adapting to diverse working environments. With a compact size of only 100*28*9mm, it takes up little space. Wiring adopts standard configuration: red (Exc+), black (Exc-), green (Sig+), white (Sig-) + yellow shield wire, enabling easy installation and high adaptability. Equipped with 0.1%FS combined error, 0.3%FS repeatability accuracy, rated output of 1.9605mv/v and insulation resistance ≥5000MΩ, the product delivers precise and reliable measurement data, making it a high-quality choice in the field of micro weighing and force measurement.
Model: MLC143
Category: Bridge load cell
Range: 0.5t, 1t, 1.5, 2t, 5t
Dimension: 100*28*9mm
Material: alloy steel,stainless steel
Characteristic: safe overload load cell, safe overload force sensor, tension force sensor
