Hydraulic Press Load Cell (MLC203B), wide range 0.1-1000t, high precision, IP66&IP68, durable for industrial heavy-load measurement.ll
Model: MLC203B
Category: button load cell
Range: 1t,2t,3t,5t,10t,20t,25t,30t
Dimension: 105*67m；121*80mm; 121*85mm
Material: alloy steel,stainless steel
Characteristic: axle scale load cell,warehouse scale load cell,experimental machine load cell
| Comprehensive error: | 0.05 % FS | Output resistance: | 700/1400 ±5Ω |
| Rated output: | 2.0±0.05mv/v | Insulation resistance: | ≥5000MΩ(100VDC) |
| Nonlinearity: | 0.0 5 %FS | Operating Voltage: | 5 ~12VDC |
| Lag: | 0.0 5 %FS | Compensation temperature: | -10 ~+ 60 ℃ |
| Repeatability: | 0.0 5 %FS | Operating temperature: | -20~+ 80 ℃ |
| Creep: | 0.0 5 %FS/10Min | Effect of Temp. on zero point: | 0.05%FS/10 ℃ |
| Zero Balance: | ±1%FS | Effect of Temp. on sensitivity: | 0.05%FS/10 ℃ |
| Input resistance: | 700/1400 ±10Ω | Protection level: | IP66 & IP68 |
