ADS-DM101C digital weighing transmitter and force measurement

ADS-DM101C digital weighing transmitter and force measurement

ADS-DM101C digital weighing transmitter is a six wire proportional measurement system with wire breakage recognition function and a 6-bit LED display screen. It can be applied in fields such as digital weighing sensors, digital weighing systems, digital force sensors, and industrial control.

ADS-DM102C is a four wire proportional measurement system that does not have wire breakage recognition function or display, but can be densely installed. During the measurement process, the nonlinear error should not exceed ± 0.05% F • S (under the condition of 15 measurements per second). The display resolution is 1/100000.

The system has multiple measurement speeds to choose from, including 15 times/second, 120 times/second, 240 times/second, 480 times/second, 960 times/second, and 1920 times/second. Users can choose the desired measurement speed through parameter settings.

In terms of communication speed, the system supports optional communication speeds ranging from 2400bps to 115200bps. The output speed of the gearbox is synchronized with the measured values, ensuring the accuracy and real-time performance of the data.

In addition, the system also has a 10 point line calibration function, which can accurately calibrate the sensor and improve measurement accuracy. The sensor power supply is 5V ± 2%, and the maximum current is 100mA.

In summary, ADS-DM101C and ADS-DM102C are two powerful proportional measurement systems that are suitable for various application scenarios and possess high accuracy, speed, and reliability.It can simultaneously have communication, transmission, input, and output functions.

DC power supply: 10-24VDC with anti reverse connection protection.


we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

  Product selection reference

Online Sales



Product Picture Reference

ADS-DM101C digital weighing transmitter and force measurement-MANYYEAR TECHNOLOGY

Technology Specification

Below spec is only for customer design reference. we can provide ODM product.
ADS-DM101C digital weighing transmitter and force measurement

Product Description

ADS-DM101C is a six wire proportional measurement system with wire breakage recognition function and a 6-bit LED display screen. It can be applied in fields such as digital weighing sensors, digital weighing systems, digital force sensors, and industrial control.

ADS-DM102C is a four wire proportional measurement system that does not have wire breakage recognition function or display, but can be densely installed. During the measurement process, the nonlinear error should not exceed ± 0.05% F • S (under the condition of 15 measurements per second). The display resolution is 1/100000.

The system has multiple measurement speeds to choose from, including 15 times/second, 120 times/second, 240 times/second, 480 times/second, 960 times/second, and 1920 times/second. Users can choose the desired measurement speed through parameter settings.

In terms of communication speed, the system supports optional communication speeds ranging from 2400bps to 115200bps. The output speed of the gearbox is synchronized with the measured values, ensuring the accuracy and real-time performance of the data.

In addition, the system also has a 10 point line calibration function, which can accurately calibrate the sensor and improve measurement accuracy. The sensor power supply is 5V ± 2%, and the maximum current is 100mA.

In summary, ADS-DM101C and ADS-DM102C are two powerful proportional measurement systems that are suitable for various application scenarios and possess high accuracy, speed, and reliability.It can simultaneously have communication, transmission, input, and output functions.

DC power supply: 10-24VDC with anti reverse connection protection.



Basic Specifications



project  specifications
supply voltageDC power supply10-24V AC 50/60 Hz; 10-24V DC
Power consumptionDC power supply102C series: less than 3.6W, typical value: 1.8W (carrying one sensor)
101C series: less than 5W
Allowable voltage variation range90%~110% of power supply voltage
insulation resistance≥ 100M Ω (500V DC MEGA reference)
Insulation strength2000V AC (test conditions: 50/60Hz, 1 minute)
Anti-interferenceIEC61000-4-2 (Electrostatic Discharge), Class III
IEC61000-4-4 (Electrical Fast Transient Pulse Group), Class III
IEC61000-4-5 (surge), Class III
Protection levelIP65 (Product Front Panel Protection) (GB/T42-2008)
Operating environmentambient temperature-10~50 ℃
Environmental humidity35~85% R • H, no condensation
Installation positionIndoor, height<2000m
 Input specifications
projectspecifications
Sensor power supplyDC 5V ± 2%, 100mA (MAX)
If 200mA (MAX) is required, it must be specified in advance when ordering
Input impedance> 10M Ω
Zero adjustment range-10~12mV
Gain input range1-12 mV
Conversion methodSigma Delta
Measurement and control speed15. 120, 240 times/second (set through parameters)
Nonlinear± 0.05% F • S (measurement and control 15bps)
(When measuring speed at 120 or 240 times/second, the non-linear error will increase)
Gain drift<10 ppm/℃
(When connecting sensors, matching terminal connectors must be used, otherwise the temperature drift characteristics will deteriorate)
measuring range-199999~999999, Decimal separator position can be set
Measurement resolution1/100000
Input signal102C series: proportional measurement, equipped with four wire strain sensors
101C series: proportional measurement, equipped with a six wire strain sensor
Contact input1 external switch input, which can be used to reset
Output specifications
projectspecifications
Compare Output2-point OC gate output, ≤ 30mA
Optional specifications
projectspecifications
Analog output
Optoelectronic isolation, resolution: 1/12000, load capacity: 600 Ω
A1Current output (4-20) mA, (0-10) mA, (0-20) mA
A2Voltage output (1-5) V, (0-5) V
A3Voltage output 0-10V
A4Voltage output ± 5V
A5Voltage output ± 10V
communication interface
102C series non isolated
Response time: 500 μ S (measured value)
MS1RS232 interface, Modbus RTU and TC ASCII protocol
MS2RS485 interface, Modbus RTU and TC ASCII protocol
Intelligent moduleTSIntelligent module
Code Description
contentCode Description
ADS-DM101C-Standard configuration: 1-point input, 2-point OC door output, 1 set for external supply.
ADS-DM102C-DM102C has no display, and the measured values and parameters of the module can be viewed through a handheld configurator (optional).
ADS-DM101C Boundary Dimensionsseventy-two × one hundred and ten point seven × 58.5, Guide rail installation.
ADS-DM102C Boundary Dimensionstwenty-three × one hundred × 114, Guide rail installation.
Transmission output (option) (isolated, resolution: 1/12000; current output load ≤ 600 Ω, voltage output load ≥ 100K Ω)A1FCurrent output (4-20) mA, (0-20) mA, (0-10) mA
A2FVoltage output (0-5) V, (1-5) V
A3FVoltage output (0-10) V
A4FVoltage output ± 5V
A5FVoltage output ± 10V
Communication (Option) (The communication interface of ADS-DM101C is isolated from the power supply, while ADS-DM102C is non isolated)MS1The RS232 interface can select TC-ASCII or Modbus-RTU protocols through parameter settings
MS2The RS485 interface can select TC-ASCII or Modbus-RTU protocols through parameter settings
Intelligent module (option)TSIntelligent module interface





Product Dimension

Product Application

ADS-DM101C digital weighing transmitter and force measurement-MANYYEAR TECHNOLOGY

apw-force-test-6

ADS-DM101C digital weighing transmitter and force measurement-MANYYEAR TECHNOLOGY

apw-force-test-7

ADS-DM101C digital weighing transmitter and force measurement-MANYYEAR TECHNOLOGY

APF-torque testing machine
