MLC161 Pin-type Load Cell (2-4t, Φ55x123mm) for cranes—alloy/stainless steel, ideal for overload limiters, testing & hook scales, accurate and durable.
Model: MLC161
Category: Pin load cell
Load range: 2t,3t,4t
Dimension: Φ55*123mm
Material: alloy steel, stainless steel
Characteristic: safety limiter load cell,overload load cell,pin load cell
| Technical specifications | |||
| Comprehensive error | 0.5%FS | Output resistance | 702±5Ω |
| Rated output | 1.0±0.005mv/v | Insulation resistance | ≥5000MΩ(100VDC) |
| Nonlinear | 0.05%FS | Operating voltage | 9~12VDC |
| Hysteresis | 0.05%FS | Compensation temperature | -10~+40 ℃ |
| Repeatability | 0.03%FS | Operating temperature | -20~+55 ℃ |
| Creep | 0.03%FS/10MIN | Effect of Temp. on zero point: | 0.05%FS/10 ℃ |
| Zero output | ±1%FS | Effect of Temp. on sensitivity: | 0.05%FS/10 ℃ |
| Input resistance | 750±10Ω | Protection level | IP66 & IP68 |
